The Scanprobe X90 pipeline inspection system sets a new benchmark in the industry, offering the capability to inspect pipelines up to 450mm with unmatched precision. Equipped with advanced features such as PDF editing, clock position observations, extended battery life, and disc brakes for enhanced control and safety, the X90 is designed for optimal performance. Its seamless integration with platforms like Outlook and WhatsApp simplifies report sharing, while compatibility with mina plus or WinCan ProTouch (optional) ensures thorough, efficient reporting. The 10-inch touch screen provides a user-friendly interface, adaptable to various operator preferences. The X90 embodies the pinnacle of pipeline inspection technology, delivering comprehensive, reliable, and efficient results.

System Components



Approvals

Contact Us

Interested about this product? Contact Us!

For all international customers please click here.

Product Specifications

Part number
  • 1008-1001-0
Weight
  • 31.3 kg
Rod Length
  • 90 meters / 295 ft
Distance Counter
  • Meters / Feet
Rod Diameter
  • 12mm
Camera Diameter
  • 44mm
Pipe Use
  • 50mm – 300mm
Capacity
  • 13.04Ah
Charge Current
  • 1.5A
Description
  • X90 Coiler
Dimensions
  • W 509mm, H 837mm, L 657mm
IP Rating
  • IP56(coiler) IP68(camerahead)
Sonde/Beacon
  • 33kHz or 512Hz
Self-levelling camera
  • Yes / Dual bearing stability
Battery Life
  • Up to 10 hours
Charge Time
  • 6 hours
Nominal Voltage
  • 7.4V
Approvals
  • CE and UKCA
